Paint Coating Thickness Tester 0–2000μm with LCD Display

Ensure precise and reliable measurements of car paint, coatings, and finishes with this high-accuracy thickness tester. Designed for professionals and enthusiasts, it delivers quick, repeatable readings on a wide range of surfaces, helping you maintain quality and avoid costly errors.

Key Features

• Measures paint and coating thickness from 0 to 2000μm with high precision

• LCD display with clear, easy-to-read 128x48 dot matrix screen

• Ruby-tipped, built-in one-piece probe for durable and accurate readings

• Fast measurement interval of 0.5 seconds for efficient workflow

• Supports multiple units: μm/mil for versatile use

• Works on both Fe (steel) and NFe (non-ferrous) substrates using Hall and Eddy current principles

• Compact and portable design for easy use in workshops or on-site

Specifications

• Measuring Range: 0.0μm – 2000μm

• Resolution: 0.1μm (0–99.9μm), 1μm (100–999μm), 0.01mm (1.00–2.00mm)

• Measurement Accuracy: ≤ ±(3% reading + 2μm)

• Minimum Measurement Area: φ = 25mm

• Minimum Curvature: Convex: 5mm / Concave: 25mm

• Minimum Substrate Thickness: Fe: 0.2mm / NFe: 0.05mm

• Operating Temperature: -20°C – 50°C

• Storage Temperature: -20°C – 60°C

• Display: 128x48 dot matrix LCD

• Power: 2 × 1.5V AAA batteries (not included)

• Size: 101 × 62 × 28mm

Package Contents

• LS220 Paint Coating Thickness Gauge × 1

What Makes This a Smart Buy:
With rapid, accurate readings and a durable ruby probe, this tester is ideal for auto body shops, detailers, and DIY enthusiasts alike. Its precision and portability make it a reliable tool for ensuring perfect paint and coating quality every time.
